QA17C CBI Earth Leakage Circuit Breaker

Africa Type QA17C CBI Earth Leakage Circuit Breaker RCCB Application

Commercial applications requiring high sensi-tivity earth leakage protection from electrical shock and firehazards Surface , Dual mount and DIN rail mounting options

Africa Type QA17C CBI Earth Leakage Circuit Breaker RCCB Features

CE approvedSmall frame size ( 26mm wide )Energy limiting capability on both switch and circuit breaker versionsSwitch version fitted with short circuit protection for additional safetyTop busbar design enables easier installationSingle pole plus switched neutral earth leakage protectionTrip point is unaffected by ambient temperatureCurrent ratings up to 63ATrip indication ( mid trip handle position

Africa Type QA17C CBI Earth Leakage Circuit Breaker RCCB Specification

• number of poles :1P, 2P,3P
• Rated current(A):6,10,16,20,25,30,40,50,63,70,80,90,100
• Breaking capacity(A):3000
• Rated voltage(V)110/220(1P), 240/415(2P),415(3P)
• Rated frequency:50/60HZ
• lectrical life:no less than 6000 operation
• Mechanical life:(O-C)no less than16000 operation
